Feature and advantage:

• The high voltage module is near to the nozzle, power saved, replaceable high voltage fitting which is convenience for repairmen.
• Stainless barrel, can easily disassembled and clean without any tools
• Rotating atomized airflow greatly improves spraying quality
• The intuitive and reasonable two flow meter shows the powder supply
• We choice of large flow of pneumatic components so even in the smaller air pressure, it can still achieve higher powder spraying
• Two-way central gas design,so that the pole needle fluid no longer powder,Strengthen the discharge effect, improve the powder rate

• Electronic technical data sheet
• Input voltage: AC200 ~ 250V
• Input power: 50W
• Operating voltage: DC12 / 24V
• Output voltage: 0-100KV (continuously adjustable)
• Output current: 0-120uA
• Input pressure: 4-8kg / m3
• Maximum powder: 600g / min
• Maximum air consumption: 25m3 / h
• Security standard: IP60 host
